Product Details

• Nominal discharge surge current (8/20): 20 kA

• Nominal discharge surge current (8/20): 20 kA

• Short-circuit breaking capacity (Isccr): 25 kA

• Max. continuous voltage AC: 275V

• Max. discharge surge current (8/20): 40 kA

• Mounting method: DIN rail (top hat rail) 35 mm

• Construction size: 1 modular spacing

• Voltage protection level: 1.3 kV

• Max. conductor cross section solid (solid, stranded): 25 mm²

• Voltage protection level L-N: 1.3 kV

• Voltage protection level N-PE: 1.3 kV

• With remote signalling contact: Yes

• Integrated backup fuse: No

• Category type 2: Yes

• Degree of protection (IP): IP20

• Standards: IEC EN 61643-11

• Frequency: 50 Hz

• CE Conformity: Yes

• WEEE Symbol: Yes

• UKCA Conformity: Yes
