Wylex NH250L4PMB 250A 4-Pole MCCB Incomer (For NH Distribution Boards Only)
PRODUCT DETAILS
**ONLY FOR 250A WYLEX DISTRIBUTION BOARDS (NOT SUITABLE FOR VM160 MCCB PANELBOARDS)
- Max. rated operation voltage Ue AC: 415 V
- Rated operating voltage: 415 V
- Rated permanent current Iu: 250 A
- Number of poles: 4
- Suitable for distribution board installation: Yes
- Degree of protection (IP), front side: IP3X
- Product Standard/s: BS EN 61439-3
- Terminal Capacity L&N: 120 mm²
- Frequency: 50 Hz
- CE Conformity: Yes
- WEEE Symbol: Yes
- UKCA Conformity: Yes
- Amperage: 250 A
- Pole Configuration: 4P
- Operating Voltage: 415 V
- Type of Current: AC
Specification
Commercial unit type |
NH Distribution |
Gtin |
5013601089887 |
Nh distribution board type |
Incoming Options |
Product type |
Incoming Options |
