Product Description

• Poles: 4P

• [Ie] rated operational current:
  63 A AC-7A
  20 A AC-7B

• pole contact composition: 2 NO + 2 NC

• network type: AC

• control type: Remote control

• [Uc] control circuit voltage: 220...240 V AC 50 Hz

• network frequency: 50 Hz

• [Ue] rated operational voltage: 400 V AC 50 Hz

• maximum power: 2.1 W at 400 V AC

• [Ui] rated insulation voltage: 500 V AC 50/60 Hz

• [Uimp] rated impulse withstand voltage: 4 kV

• control signal type: Maintained

• switching frequency: 100 switching operations/day

• local signalling: Action indicator

• hold-in power consumption in VA: 6.5 VA

• inrush power in VA: 53 VA

• mounting mode: Clip-on

• mounting support: 35 mm symmetrical DIN rail

• 9 mm pitches: 6

• height: 85 mm
• width: 54 mm
• depth: 60 mm

• mechanical durability: 1000000 cycles
