Product Functionality

• Long range with narrow angle detection

• Fully remote configurable through App

• Multiple enrollment method and easy installation design

• Easy replaceable battery with PCB protected

• Frequency hopping against jamming for reliable transmission

Product Details

• Detection Method: Passive Infrared

• Detection Range: 15m

• Detection Angle: 6.3 °

• Detection Zones: 18

• Detectable Speed: 0.3～2m/s

• Pet Immunity: None

• White Light Filter: 6500lux

• Digital Temperature Compensation: Support

• Creep Zone Protection: Support

• Standard Battery Life: 5 years in work status (being triggered 20 times per day)

• Power Supply: Battery Powered

• Battery Type: CR123A × 1

• Typical Voltage: 3V

• Dimension(WxHxD): 65.5mm × 103mm × 48.5mm

• Weight: 128g

• Mounting Height: 1.8 to 2.4m

• Application: Indoor

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 868MHz

• Transmission Security: AES-128 Encryption

• Transmission Range(Free Space): 1.6Km

• Frequency Hopping: Support

• Enrolling Method: Power up;Remote ID;QR Code
