Hager NBN120A 20A, 1-Pole, 10kA-15kA, B-Type MCB
Technical Details
- Number of Poles: 1
- Curve: B
- Rating current 30 °C: 20 A
- Dimensions (HxWxD): 83 x 17.5 x 70mm
- Rated Frequency: 50/60 Hz
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 6000 V
- Rated service breaking capacity Ics AC according IEC 60898-1: 7.5 kA
- Rated short circuit breaking capacity Icn under 230V AC according IEC60898-1: 10 kA
- Total power loss under IN: 1.33 W
-
Standard text:
- EN 60898-1
- IEC 60947-2
- European directive WEEE: concerned
- Electric endurance in number of cycles: 4000
- Number of mechanical operations: 20000
- Protection index IP: IP20
Specification
Depth |
70mm |
Enclosure material |
Metal |
Flexible configuration |
No |
Gtin |
3250614618055 |
Height |
83mm |
Internal external |
Internal |
Populated |
No |
Product type |
MCB Units |
Width |
17.5mm |
