STANDARD

EN 61439-3

RATED VOLTAGE (Un/AC)

230V

FREQUENCY (Hz)

50/60

PROTECTION DEGREE (IP)

2XC

MAXIMUM TERMINAL BAR CAPACITY

16mm ²

TERMINAL BAR TIGHTENING TORQUE (Nm)

2

DEVICE MOUNTING

35mm DIN RAIL

MATERIAL

1mm ELECTRO GALVANISED STEEL (ZINC)

FINISH

RAL 9001 POWDER COATED SMOOTH FINISH

KNOCKOUTS

SELECTION 20mm - 40mm

ACCESSORY PACK

CIRCUIT IDENTIFICATION LABELS / GROMMET STRIP

NUMBER OF USABLE WAYS

30

SPLIT

15/15

PART NUMBER

F2030MDT

GTIN-13

5060523524358

MAIN SWITCH RATING (AC22A)

100A

WEIGHT (1PC) Kg

8.1

DIMENSIONS (HxWxD)mm

512x378x113

DOUBLE BANK

Y

TAIL CLAMP COMPATIBLE (ACCF)

Y
