Product Description

• Terminal Type: Box clamp

• Current Rating: 20A

• Terminal Capacity: 1 -25mm²

• Terminal Screw: M5 Combination

• Terminal Torque: 2.0Nm - 2.4Nm max

• Mounting: DIN rail

• Degree of Protection: IP20

• Positive Contact Indication: Red/Green flag indicator

• Rated Volume: 230/240 V AC, 48V DC (per pole)

• Rated Impulse and Withstand VOltage: 4kV (1.2/50) u sec

• Rated Short Circuit Capacity: 10kA to IEC EN 60898 and 15kA to IEC EN 60947-2

• Selectivity Class: 3 to EN 60898

• Instanteneous Tripping Current: 3 In < Imt< 5 In

• Conventional Non-Tripping Current: I nt = 1.45 In

• Ref/Ca;ibration Temperature: 40° C

• Number of Operating Cycles Elec: >4000

• Number of Operating Cycles Mech: >2000
