Product Features

• Max. 15 fps@4K.

• 120 dB true WDR, 3D NR.

• Smart Dual-Illumination.

• 40 m illumination distance.

• Super Adapt.

• Built-in MIC.

• 2.8mm fixed lens

• CVI/CVBS/AHD/TVI switchable.

• IP67, 12 VDC

Functions

Wide Dynamic Range: With its advanced Wide Dynamic Range (WDR) technology, the camera captures highly detailed images and produces high-definition recordings in high-contrast lighting conditions, including scenes with backlighting or shadows.

Broadcast-Quality Audio: The camera supports audio signal transmission over coaxial cables. It employs unique audio processing and transmission technology that restores source audio and eliminates noise, ensuring the quality and reliability of the audio information collected. This is crucial for video surveillance applications that use audio information as supplementary evidence.

Smart Dual-Illumination: Featuring a smart dual-light mechanism, the camera automatically activates the white light when the Perimeter Protection/SMD Plus
function of AI XVR detects a target in the designated area, capturing clear, vivid images. Once the target exits the area, the camera switches from white light to IR light, significantly reducing light pollution

Super Adapt: Equipped with an intelligent algorithm, the camera automatically
adjusts its parameters to deliver optimal performance and vivid images

Advanced 3DNR: The camera’s advanced 3DNR technology reduces image noise with
minimal impact on image sharpness, especially in low-light conditions. It detects noise and compares sequential frames to effectively reduce it, also efficiently using bandwidth and saving storage space.

Protection (IP67, Wide Voltage): IP67: The camera has passed a series of rigorous dust and immersion tests. Its enclosure is both dust-proof and waterproof, capable of
functioning normally while submerged in 1 metre of water for up to 30 minutes. Wide voltage: The camera has ±30% input voltage tolerance (for some power supplies) and a wide voltage range, making it suitable for various outdoor scenarios.

4 Signals over 1 Coaxial Cable: The technology supports four signals (video, audio, data, and power) transmitted simultaneously over a coaxial cable. Dual-way data transmission allows the camera to interact with the XVR for actions such as sending control signals and triggering alarms. This technology also supports PoC, making the camera easy and quick to install.

Long Distance Transmission: The technology provides long-distance transmission in real-time without transmission loss. It supports transmission distances up to 700 metres for 2-MP/5-MO/8-MP HD videos through coaxial cables, and up to 300 metres through UTP cables. These results were obtained and verified through rigorous testing
