Product Details:

Approvals/certifications : Certified to EN54- by by UL International (UK) Limited.

Application/operation : Designed to be ceiling mounted with an AlarmSense fire detector. Red and White caps available for stand alone use.

Supply wiring : 2-wire monitored, polarity insensitive.

Supply/operating voltage : 18-33VDC (sounders active); Less than 15VDC (sounders off).

Quiescent current : Less than 20µA @ 12VDC.

Nominal SPL (Sound Pressure Level) : 87dB(A) max (high volume setting); 70dB(A) nominal (low volume setting).

Alarm current : 5mA (sounder active current at 24V).

Product dimensions (mm) : 115mm diameter x 40mm deep (without optional AlarmSense detector).

Construction & finish : White polycarbonate. Red and white caps available for stand alone use.

IP Rating : TBC.

Weight : 150g

Key Features:

• Will accept any AlarmSense fire detector to provide fire detection and an audible alarm warning signal at the same point.

• 70d-87dB(A) sound output.

• Suitable for use with C-TEC’s CFP AlarmSense range of 2-8 Zone Two-Wire Fire Panels.

• AlarmSense priority/non priority signal recognition

• Detects the removal of a detector head and reports a fault

• Continues to work during unauthorised removal of detector.

• High and low volume ranges

• Red and white caps available for stand-alone use.
